TOP PCB KB6160 FR4 Double sides PCB printed circuit board China Manufacture 4 layer pcb circuits for Multilayer PCB
Product Description
Our Advantages
✔ Program and functional test and package by Free.
✔ High quality: IPC-A-610E standard, E-test, X-ray, AOI test, QC, 100% functional test.
✔ Professional service: PCB/FPC/Aluminium Making, SMT, DIP, Component Sourcing, OEM with 12 years experience.
✔ Certifications: UL, 94v-0, CE, SGS, FCC, RoHS, ISO9001:2008, ISO14001, ISO13485, TS16949.
✔ The warranty period for PCBA: 2 years.
✔ About Factory: 13 SMT Lines, 5 DIP Lines, 1 X-ray, 13 AOI, 2 Sample test machines.
PCB & PCBA Capacity
| Items |
Capacity |
| 1. Material |
FR4, (High Tg FR4, General Tg FR4, Middle Tg FR4), Lead-Free Solder Sheet, Halogen Free FR4, Ceramic Filling Material, Teflon, PI Material, BT Material, PPO, PPE etc. |
| 2. Board thickness |
Mass production: 394mil(10mm) Samples: 17.5mm |
| 3. Surface finish |
HASL, Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger |
| 4. PCB Max panel size |
1150mm × 560mm |
| 5. Layer |
Mass production: 2~58 layers / Pilot run: 64 layers, Flexible PCB: 1-12 Layers |
| 6. Min hole size |
Mechanical drill: 8mil(0.2mm) Laser drill: 3mil(0.075mm) |
| 7. PCBA QC |
X-ray, AOI Test, Functional Test |
Product Display
About Us
We provide the following services to our clients: Schematic Design & Board Layout, PCB & FPC Manufacturing, Metal Injection Molding, Global Supply Chain Management, and PCB Assembly Service to deliver finished goods or drop shipping. If you require only one aspect of the above, we have the flexibility to match your needs and requirements.
We provide one-stop PCBA services, such as 0201/BGA/CCGA surface-mount(SMT), thru-hole(THT), mixed technology (SMT & thru-hole), conformal coating, potting and encapsulations, AOI/X-Ray PCBA testing, IC programming, box building service, etc. The PCBA is used in telecommunications, automotive electronics, 3G/4G/5G products, IOT products, AI smart control products, RF, networking, security, industrial control, medical instrumentation, military products, computer peripherals, and other high-tech fields.
Certificates
Customer Visitor & Feedback
Packing & Shipping
Frequently Asked Questions
1. Q: What files do you use in PCBA fabrication?
A: Gerber or Eagle, BOM listing, PNP and Components Position.
2. Q: Is it possible you could offer samples?
A: Yes, we can custom samples for your testing before mass production.
3. Q: How much time could I get the quotation after sending Gerber and BOM?
A: Within 6 hours for PCB quotation and around 24 hours for PCBA quotation.
4. Q: How can I know the process of my PCBA production?
A: 7-10 days for PCB production and components purchasing, and 10 days for PCB assembly and Testing.
5. Q: Are my designs secure when I send them to you?
A: Your files are held in complete safety and security. They are never shared with any third parties; only authorized colleagues have access to your design files. We respect the copyright of your files.
6. Q: What is the warranty?
A: The warranty is 2 years.
